ABB ACS880 - Page 209

Def / Type
FbEq 16b / 32b
DescriptionName / Range /
Selection
No.
10 = 1 s / 100 = 1 sDeactivation delay for DI3.0.00 ... 3000.00 s
0.00 s / real32
(Visible when 14.1 Module 1 type = FIO-01)
Defines the deactivation delay for digital input/output DIO3.
See parameter 14.12 DIO1 ON delay.
DIO3 OFF delay14.23
10 = 1 s / 100 = 1 sDeactivation delay for DIO3.0.00 ... 3000.00 s
Input / uint16
(Visible when 14.1 Module 1 type = FIO-01)
Selects whether DIO4 of the extension module is used as
a digital input or output.
DIO4 function14.24
0DIO4 is used as a digital output.Output
1DIO4 is used as a digital input.Input
- / real32
(Visible when 14.1 Module 1 type = FAIO-01)
Displays the value of analog input AI1 in mA or V
(depending on whether the input is set to current or
voltage).
This parameter is read-only.
AI1 actual value14.26
1000 = 1 mA or V /
1000 = 1 mA or V
Value of analog input AI1.-22.000 ... 22.000 mA
or V
Not energized / uint32
(Visible when 14.1 Module 1 type = FIO-01)
Selects a drive signal to be connected to digital input/output
DIO4 when parameter 14.24 DIO4 function is set to Output.
For the available selections, see parameter 14.11 DIO1
output source.
DIO4 output source14.26
- / real32
(Visible when 14.1 Module 1 type = FAIO-01)
Displays the value of analog input AI1 after scaling. See
parameter 14.35 AI1 scaled at AI1 min.
This parameter is read-only.
AI1 scaled value14.27
1 = 1 / 1000 = 1Scaled value of analog input AI1.-32768.000 ...
32767.000
0.00 s / real32
(Visible when 14.1 Module 1 type = FIO-01)
Defines the activation delay for digital input/output DIO4.
See parameter 14.12 DIO1 ON delay.
DIO4 ON delay14.27
10 = 1 s / 100 = 1 sActivation delay for DIO4.0.00 ... 3000.00 s
- / real32
(Visible when 14.1 Module 1 type = FAIO-01)
Forced value that can be used instead of the true reading
of the input. See parameter 14.22 AI force selection.
AI1 force data14.28
1000 = 1 mA or V /
1000 = 1 mA or V
Forced value of analog input AI1.-22.000 ... 22.000 mA
or V
0.00 s / real32
(Visible when 14.1 Module 1 type = FIO-01)
Defines the deactivation delay for digital input/output DIO4.
See parameter 14.12 DIO1 ON delay.
DIO4 OFF delay14.28
10 = 1 s / 100 = 1 sDeactivation delay for DIO4.0.00 ... 3000.00 s
Parameters 209
