Def / Type
FbEq 16b / 32b
DescriptionName / Range /
Selection
No.
Not selected / uint32
When bit 0 of parameter 28.21 Constant frequency function
is 0 (Separate), selects a source that activates constant
frequency 1.
When bit 0 of parameter 28.21 Constant frequency function
is 1 (Packed), this parameter and parameters 28.23
Constant frequency sel2 and 28.24 Constant frequency
sel3 select three sources whose states activate constant
frequencies as follows:
Constant fre-
quency active
Source
defined by
par. 28.24
Source
defined by
par. 28.23
Source
defined by
par. 28.22
None000
Constant fre-
quency 1
001
Constant fre-
quency 2
010
Constant fre-
quency 3
011
Constant fre-
quency 4
100
Constant fre-
quency 5
101
Constant fre-
quency 6
110
Constant fre-
quency 7
111
Constant frequency
sel1
28.22
00Not selected
11Selected
2
Digital input DI1 (10.2 DI delayed status, bit 0).
DI1
3
Digital input DI2 (10.2 DI delayed status, bit 1).
DI2
4
Digital input DI3 (10.2 DI delayed status, bit 2).
DI3
5
Digital input DI4 (10.2 DI delayed status, bit 3).
DI4
6
Digital input DI5 (10.2 DI delayed status, bit 4).
DI5
7
Digital input DI6 (10.2 DI delayed status, bit 5).
DI6
10
Digital input/output DIO1 (11.2 DIO delayed status, bit 0).
DIO1
11
Digital input/output DIO2 (11.2 DIO delayed status, bit 1).
DIO2
Source selection See Terms and abbreviations (page 132).
Other [bit]
Not selected / uint32
When bit 0 of parameter 28.21 Constant frequency function
is 0 (Separate), selects a source that activates constant
frequency 2.
When bit 0 of parameter 28.21 Constant frequency function
is 1 (Packed), this parameter and parameters 28.22
Constant frequency sel1 and 28.24 Constant frequency
sel3 select three sources that are used to activate constant
frequencies.
See table at parameter 28.22 Constant frequency sel1.
For the selections, see parameter 28.22 Constant
frequency sel1.
Constant frequency
sel2
28.23
