Def / Type
FbEq 16b / 32b
DescriptionName / Range /
Selection
No.
3If the drive is modulating, the external event generates a
fault.
Otherwise, the event generates a warning.
Warning/Fault
Inactive (true) / uint32Defines the source of external event 4. See also parameter
31.8 External event 4 type.
For the selections, see parameter 31.1 External event 1
source.
External event 4
source
31.7
- / uint16Selects the type of external event 4.External event 4 type31.8
0The external event generates a fault.Fault
1The external event generates a warning.Warning
3If the drive is modulating, the external event generates a
fault.
Otherwise, the event generates a warning.
Warning/Fault
Inactive (true) / uint32Defines the source of external event 5. See also parameter
31.10 External event 5 type.
For the selections, see parameter 31.1 External event 1
source.
External event 5
source
31.9
- / uint16Selects the type of external event 5.External event 5 type31.10
0The external event generates a fault.Fault
1The external event generates a warning.Warning
3If the drive is modulating, the external event generates a
fault.
Otherwise, the event generates a warning.
Warning/Fault
DI3 / uint32Selects the source of an external fault reset signal. This
signal will be observed even if it is not the active source in
the current control location (EXT1/EXT2/Local).
(A reset from the active source will be observed regardless
of this parameter.)
0 → 1 = Reset
Fault reset selection31.11
00Not selected
11Selected
2
Digital input DI1 (10.2 DI delayed status, bit 0).
DI1
3
Digital input DI2 (10.2 DI delayed status, bit 1).
DI2
4
Digital input DI3 (10.2 DI delayed status, bit 2).
DI3
5
Digital input DI4 (10.2 DI delayed status, bit 3).
DI4
6
Digital input DI5 (10.2 DI delayed status, bit 4).
DI5
7
Digital input DI6 (10.2 DI delayed status, bit 5).
DI6
10
Digital input/output DIO1 (11.2 DIO delayed status, bit 0).
DIO1
11
Digital input/output DIO2 (11.2 DIO delayed status, bit 1).
DIO2
30Control word bit 7 received through fieldbus interface A.FBA A MCW bit 7
32Control word bit 7 received through the embedded fieldbus
interface.
EFB MCW bit 7
Source selection See Terms and abbreviations (page 132).
Other [bit]
Parameters 331
