Def / Type
FbEq 16b / 32b
DescriptionName / Range /
Selection
No.
Fault; No action (95.20
b15) / uint16
Selects how the drive reacts to incorrect input power and
motor cable connection (i.e. input power cable is connected
to drive motor connection).
Note: The protection must be disabled with drive/inverter
hardware supplied from a common DC bus.
Wiring or earth fault31.23
0No action taken (protection disabled).No action
1
The drive trips on fault 3181 Wiring or earth fault.
Fault
Fault / uint16Selects how the drive reacts to a motor stall condition.
A stall condition is defined as follows:
•
The drive exceeds the stall current limit (31.25 Stall
current limit), and
• the output frequency is below the level set by
parameter 31.27 Stall frequency limit or the motor
speed is below the level set by parameter 31.26 Stall
speed limit, and
• the conditions above have been true longer than the
time set by parameter 31.28 Stall time.
Stall function31.24
0None (stall supervision disabled).No action
1
The drive generates an A780 Motor stall.
Warning
2
The drive trips on fault 7121 Motor stall.
Fault
200.0 % / real32Stall current limit in percent of the nominal current of the
motor. See parameter 31.24 Stall function.
Stall current limit31.25
10 = 1 % / 10 = 1 %Stall current limit.0.0 ... 1600.0 %
150.00; 180.00 rpm
(95.20 b0) rpm / real32
Stall speed limit in rpm. See parameter 31.24 Stall function.
Stall speed limit31.26
- / -
Stall speed limit. For scaling, see parameter 46.1.
0.00 ... 10000.00 rpm
15.00; 18.00 Hz (95.20
b0) Hz / real32
Stall frequency limit. See parameter 31.24 Stall function.
Note: Setting the limit below 10 Hz is not recommended.
Stall frequency limit31.27
- / -
Stall frequency limit. For scaling, see parameter 46.2.
0.00 ... 500.00 Hz
20 s / real32
Stall time. See parameter 31.24 Stall function.
Stall time31.28
1 = 1 s / 1 = 1 sStall time.0...3600 s
336 Parameters
