ABB ACS880 - Page 379

Def / Type
FbEq 16b / 32b
DescriptionName / Range /
Selection
No.
Not selected / uint32
Selects, together with 40.20 Set 1 internal setpoint sel2,
the internal setpoint out of the presets defined by
parameters 40.21…40.24.
Setpoint
preset active
Source defined by
par. 40.20
Source defined by
par. 40.19
1 (par. 40.21)
00
2 (par. 40.22)
01
3 (par. 40.23)
10
4 (par. 40.24)
11
Set 1 internal setpoint
sel1
40.19
00Not selected
11Selected
2
Digital input DI1 (10.2 DI delayed status, bit 0).
DI1
3
Digital input DI2 (10.2 DI delayed status, bit 1).
DI2
4
Digital input DI3 (10.2 DI delayed status, bit 2).
DI3
5
Digital input DI4 (10.2 DI delayed status, bit 3).
DI4
6
Digital input DI5 (10.2 DI delayed status, bit 4).
DI5
7
Digital input DI6 (10.2 DI delayed status, bit 5).
DI6
10
Digital input/output DIO1 (11.2 DIO delayed status, bit 0).
DIO1
11
Digital input/output DIO2 (11.2 DIO delayed status, bit 1).
DIO2
Source selection See Terms and abbreviations (page 132).
Other [bit]
Not selected / uint32
Selects, together with 40.19 Set 1 internal setpoint sel1,
the internal setpoint out of the presets defined by
parameters 40.21…40.24. See table at 40.19 Set 1 internal
setpoint sel1.
Set 1 internal setpoint
sel2
40.20
00Not selected
11Selected
2
Digital input DI1 (10.2 DI delayed status, bit 0).
DI1
3
Digital input DI2 (10.2 DI delayed status, bit 1).
DI2
4
Digital input DI3 (10.2 DI delayed status, bit 2).
DI3
5
Digital input DI4 (10.2 DI delayed status, bit 3).
DI4
6
Digital input DI5 (10.2 DI delayed status, bit 4).
DI5
7
Digital input DI6 (10.2 DI delayed status, bit 5).
DI6
10
Digital input/output DIO1 (11.2 DIO delayed status, bit 0).
DIO1
11
Digital input/output DIO2 (11.2 DIO delayed status, bit 1).
DIO2
Source selection See Terms and abbreviations (page 132).
Other [bit]
- / real32
Defines process setpoint preset 1. See parameter 40.19
Set 1 internal setpoint sel1.
The unit is selected by parameter 40.12 Set 1 unit
selection.
Set 1 internal setpoint
1
40.21
1 = 1 / 100 = 1Process setpoint preset 1.-32768.00 ...
32767.00
Parameters 379
