Def / Type
FbEq 16b / 32b
DescriptionName / Range /
Selection
No.
00Not selected
11Selected
2
Digital input DI1 (10.2 DI delayed status, bit 0).
DI1
3
Digital input DI2 (10.2 DI delayed status, bit 1).
DI2
4
Digital input DI3 (10.2 DI delayed status, bit 2).
DI3
5
Digital input DI4 (10.2 DI delayed status, bit 3).
DI4
6
Digital input DI5 (10.2 DI delayed status, bit 4).
DI5
7
Digital input DI6 (10.2 DI delayed status, bit 5).
DI6
10
Digital input/output DIO1 (11.2 DIO delayed status, bit 0).
DIO1
11
Digital input/output DIO2 (11.2 DIO delayed status, bit 1).
DIO2
Source selection See Terms and abbreviations (page 132).
Other [bit]
Not selected / uint32Selects the value source for tracking mode. See parameter
40.49 Set 1 tracking mode.
Set 1 tracking ref
selection
40.50
0None.Not selected
1
12.12 AI1 scaled value (page 189).
AI1 scaled
2
12.22 AI2 scaled value (page 191).
AI2 scaled
3
3.5 FB A reference 1 (page 142).
FB A ref1
4
3.6 FB A reference 2 (page 142).
FB A ref2
See Terms and abbreviations (page 132).
Other
Off / uint16Activates the trim function and selects between direct and
proportional trimming (or a combination of both). With
trimming, it is possible to apply a corrective factor to the
drive reference (setpoint). The output after trimming is
available as parameter 40.5 Process PID trim output act.
See the control chain diagram on page 641.
Set 1 trim mode40.51
0The trim function is inactive.Off
1The trim function is active. The trimming factor is relative
to the maximum speed, torque or frequency; the selection
between these is made by parameter 40.52 Set 1 trim
selection.
Direct
2The trim function is active. The trimming factor is relative
to the reference selected by parameter 40.53 Set 1 trimmed
ref pointer.
Proportional
3The trim function is active. The trimming factor is a
combination of both Direct and Proportional modes; the
proportions of each are defined by parameter 40.54 Set 1
trim mix.
Combined
Torque / uint16Selects whether trimming is used for correcting the speed,
torque or frequency reference.
Set 1 trim selection40.52
1Torque reference trimming.Torque
2Speed reference trimming.Speed
3Frequency reference trimming.Frequency
386 Parameters
