Def / Type
FbEq 16b / 32b
DescriptionName / Range /
Selection
No.
5
The scaling is defined by parameter 46.2 Frequency
scaling.
Frequency
Auto / uint16Selects the type and scaling of reference 2 received from
fieldbus adapter A.
See parameter 50.4 FBA A ref1 type.
FBA A ref2 type50.5
Auto / uint16Selects the type/source and scaling of actual value 1
transmitted to the fieldbus network through fieldbus adapter
A.
Note: Fieldbus-specific communication profiles may use
different scalings. For more information, see the manual
of the fieldbus adapter.
FBA A actual 1 type50.7
0Type/source and scaling follow the type of reference 1
selected by parameter 50.4 FBA A ref1 type. See the
individual settings below for the sources and scalings.
Auto
1
The value selected by parameter 50.10 FBA A act1
transparent source is sent as actual value 1. No scaling is
applied (the 16-bit scaling is 1 = 1 unit).
Transparent
2
The value selected by parameter 50.10 FBA A act1
transparent source is sent as actual value 1 with a 16-bit
scaling of 100 = 1 unit (ie. integer and two decimals).
General
3
1.10 Motor torque is sent as actual value 1. The scaling is
defined by parameter 46.3 Torque scaling.
Torque
4
1.1 Motor speed used is sent as actual value 1. The scaling
is defined by parameter 46.1 Speed scaling.
Speed
5
1.6 Output frequency is sent as actual value 1. The scaling
is defined by parameter 46.2 Frequency scaling.
Frequency
6Motor position is sent as actual value 1. See parameter
90.6 Motor position scaled.
Position
Auto / uint16Selects the type/source and scaling of actual value 2
transmitted to the fieldbus network through fieldbus adapter
A.
See parameter 50.7 FBA A actual 1 type.
FBA A actual 2 type50.8
Not selected / uint32Selects the source of the fieldbus status word when the
fieldbus adapter is set to a transparent communication
profile eg. by its configuration parameters (group 51 FBA
A settings).
FBA A SW
transparent source
50.9
0No source selected.Not selected
See Terms and abbreviations (page 132).
Other
Not selected / uint32
When parameter 50.7 FBA A actual 1 type is set to
Transparent or General, this parameter selects the source
of actual value 1 transmitted to the fieldbus network through
fieldbus adapter A.
FBA A act1
transparent source
50.10
0No source selected.Not selected
See Terms and abbreviations (page 132).
Other
Parameters 417
