Def / Type
FbEq 16b / 32b
DescriptionName / Range /
Selection
No.
Status of follower 14 is monitored.Follower 14b13
Status of follower 15 is monitored.Follower 15b14
Status of follower 16 is monitored.Follower 16b15
1 = 10000h…FFFFh
- / uint16Selects the followers (out of followers 17…32) whose status
words are monitored by the D2D master.
Note: Also activate communication supervision for the
same followers in parameter 60.20 M/F comm supervision
sel 2.
See parameter 60.23 M/F status supervision sel 1.
M/F status
supervision sel 2
60.24
1 = Status of follower 17 is monitored.Follower 17b0
1 = Status of follower 18 is monitored.Follower 18b1
1 = Status of follower 19 is monitored.Follower 19b2
1 = Status of follower 20 is monitored.Follower 20b3
1 = Status of follower 21 is monitored.Follower 21b4
1 = Status of follower 22 is monitored.Follower 22b5
1 = Status of follower 23 is monitored.Follower 23b6
1 = Status of follower 24 is monitored.Follower 24b7
1 = Status of follower 25 is monitored.Follower 25b8
1 = Status of follower 26 is monitored.Follower 26b9
1 = Status of follower 27 is monitored.Follower 27b10
1 = Status of follower 28 is monitored.Follower 28b11
1 = Status of follower 29 is monitored.Follower 29b12
1 = Status of follower 30 is monitored.Follower 30b13
1 = Status of follower 31 is monitored.Follower 31b14
1 = Status of follower 32 is monitored.Follower 32b15
1 = 10000h…FFFFh
- / uint16
In the D2D master, parameters 60.27 M/F status supv
mode sel 1 and 60.28 M/F status supv mode sel 2 specify
the mode of follower status word monitoring. Each follower
can individually be set to be monitored continuously, or
only when it is in stopped state.
This parameter selects the mode of status word monitoring
of followers 1…16.
M/F status supv mode
sel 1
60.27
0 = Status of follower 1 is monitored continuously.
1 = Status of follower 1 is monitored only when it is in
stopped state.
Follower 1b0
0 = Status of follower 2 is monitored continuously.
1 = Status of follower 2 is monitored only when it is in
stopped state.
Follower 2b1
0 = Status of follower 3 is monitored continuously.
1 = Status of follower 3 is monitored only when it is in
stopped state.
Follower 3b2
448 Parameters
