Def / Type
FbEq 16b / 32b
DescriptionName / Range /
Selection
No.
- / uint32Displays the raw measurement data of encoder 2 position
(within one revolution) as a 24-bit unsigned integer received
from the encoder interface.
Note: This parameter is read-only.
Encoder 2 position
raw
90.24
- / -Raw encoder 2 position within one revolution.0...16777215
- / uint32Displays the revolutions of (multiturn) encoder 2 within its
value range (see parameter 93.14 Revolution data width)
as a raw measurement.
Note: This parameter is read-only.
Encoder 2 revolutions
raw
90.25
- / -Raw encoder 2 revolution count.0...16777215
- / int32Displays the motor revolution count extension.
The counter is incremented when the position selected by
90.41 Motor feedback selection wraps around in the
positive direction, and decremented in the negative
direction.
Note: This parameter is read-only.
Motor revolution
extension
90.26
- / -Motor revolution count extension.-2147483648...2147483647
- / int32Displays the load revolution count extension.
The counter is incremented when the position selected by
90.51 Load feedback selection wraps around in the positive
direction, and decremented in the negative direction.
Note: This parameter is read-only.
Load revolution
extension
90.27
- / -Load revolution count extension.-2147483648...2147483647
- / uint16Status information related to the position counter function.
See section Position counter (page 56).
Note: This parameter is read-only.
Pos counter status90.35
1 = Encoder 1 selected as load feedback sourceEncoder 1 feedbackb0
1 = Encoder 2 selected as load feedback sourceEncoder 2 feedbackb1
1 = Internal load position estimate selected as load
feedback source
Internal position
feedback
b2
1 = Motor feedback selected as load feedback sourceMotor feedbackb3
0 = Position counter not initialized, or encoder feedback
was lost. Fresh counter initialization recommended.
1 = Position counter successfully initialized
Pos counter init readyb4
1 = Position counter initialization is being prevented by par.
90.68
Position counter
re-init disabled
b5
1 = Encoder feedback intermittent or lost. (If the drive is
running, estimated position is used whenever encoder
feedback is unavailable. If the drive is in stopped state,
position counting will continue based on encoder data after
the connection is restored.)
Position data
inaccurate
b6
Reservedb7…15
1 = 10000h…FFFFh
Parameters 475
