ABB ACS880 - Page 514

Def / Type
FbEq 16b / 32b
DescriptionName / Range /
Selection
No.
1 = Tick received: Tick has been received through fieldbus
interface A.
FbusAb7
1 = Tick received: Tick has been received through fieldbus
interface B.
FbusBb8
1 = Tick received: Tick has been received through the
embedded fieldbus interface.
EFBb9
Reservedb10
1 = Tick received: Tick has been received from the control
panel, or Drive Composer PC tool connected to the control
panel.
Panel linkb11
1 = Tick received: Tick has been received from Drive
Composer PC tool through an FENA module.
Ethernet tool linkb12
1 = Tick received: Tick has been set by parameters
96.24 … 96.26.
Parameter settingb13
1 = RTC time in use: Time and date have been read from
the real-time clock.
RTCb14
1 = Drive on-time in use: Time and date are displaying
drive on-time.
Drive On-Timeb15
1 = 10000h…FFFFh
0 / uint16Specifies an ID number for the drive. The ID can be read
by an external controller through DDCS, for example, for
comparison with an ID contained by the controller's
application.
Drive ID number96.31
1 = 1 / 1 = 1ID number.0...32767
Enable / uint16Enables/disables power-up logging. When enabled, an
event (B5A2 Power up) is logged by the drive upon each
power-up.
Power up event
logging
96.39
0Power-up event logging disabled.Disable
1Power-up event logging enabled.Enable
- / uint16Clears the contents of the event logs. See section
Warning/fault history and analysis (page 538).
Clear fault and event
logger
96.51
1 = 1 / 1 = 100001 = Clear the event logs. (The value will automatically
revert to 00000.)
0...65535
0 / uint32Displays the actual parameter configuration checksum.
The checksum is generated and updated whenever an
action is selected in 96.54 Checksum action.
The parameters included in the calculation have been
pre-selected, but the selection can be edited using the
Drive customizer PC tool.
See also section Parameter checksum
calculation (page 102).
Actual checksum96.53
1 = 1Actual checksum.00000000…FFFFFFFFh
No action / uint16Selects how the drive reacts if the parameter checksum
(96.53 Actual checksum) does not match any of the active
approved checksums (96.56 … 96.59). The active
checksums are selected by 96.55 Checksum control word.
Checksum action96.54
514 Parameters
