Def / Type
FbEq 16b / 32b
DescriptionName / Range /
Selection
No.
2Fieldbus interface A or B.Fieldbus A or B
3Fieldbus interface A.Fieldbus A
4Fieldbus interface B.Fieldbus B
5The master station on a master/follower or drive-to-drive
link.
D2D or M/F
6Embedded fieldbus interface.Embedded FB
8Control panel, or Drive Composer PC tool connected to
the control panel.
Panel link
9Drive Composer PC tool through an FENA module.Ethernet tool link
Inactive / uint16In the master drive, activates clock synchronization for
master/follower and drive-to-drive communication.
M/F and D2D clock
synchronization
96.23
0Clock synchronization not active.Inactive
1Clock synchronization active.Active
- / uint16Number of full days passed since beginning of the year
1980. This parameter, together with 96.25 Time in minutes
within 24 h and 96.26 Time in ms within one minute makes
it possible to set the date and time in the drive via the
parameter interface from a fieldbus or application program.
This may be necessary if the fieldbus protocol does not
support time synchronization.
Full days since 1st
Jan 1980
96.24
1 = 1 days / 1 = 1 daysDays count. 1 = 1st January 1980.1...59999 days
0 min / uint16Number of full minutes passed since midnight. For
example, the value 860 corresponds to 2:20 pm.
See parameter 96.24 Full days since 1st Jan 1980.
Time in minutes within
24 h
96.25
1 = 1 min / 1 = 1 minMinutes since midnight.0...1439 min
0 ms / uint16Number of milliseconds passed since last minute.
See parameter 96.24 Full days since 1st Jan 1980.
Time in ms within one
minute
96.26
1 = 1 ms / 1 = 1 msNumber of milliseconds since last minute.0...59999 ms
- / uint16Time source status word.
Note: This parameter is read-only.
Time sync source
status
96.29
1 = 1st priority tick received: Tick has been received from
1st priority source (or from 96.24 … 96.26).
Time tick receivedb0
1 = 2nd priority tick received: Tick has been received from
2nd priority source.
Aux Time tick
received
b1
1 = Yes: Tick interval too long (accuracy compromised).Tick interval is too
long
b2
1 = Tick received: Tick has been received from an external
controller.
DDCS controllerb3
1 = Tick received: Tick has been received through the
master/follower link.
Master/Followerb4
Reservedb5
1 = Tick received: Tick has been received through the
drive-to-drive link.
D2Db6
Parameters 513
