Def / Type
FbEq 16b / 32b
DescriptionName / Range /
Selection
No.
- / uint16Provides status information on the user data logger. See
section Warning/fault history and analysis (page 538).
Note: This parameter is read-only.
User data logger
status word
96.61
1 = The user data logger is running. The bit is cleared after
the post-trigger time has passed.
Runningb0
1 = The user data logger has been triggered. The bit is
cleared when the logger is restarted.
Triggeredb1
1 = The user data logger contains data that can be read.
Note that the bit is not cleared because the data is saved
to the memory unit.
Data availableb2
1 = The user data logger has been configured. Note that
the bit is not cleared because the configuration data is
saved to the memory unit.
Configuredb3
Reservedb4…15
1 = 10000h…FFFFh
Off / uint32Triggers, or selects a source that triggers, the user data
logger.
User data logger
trigger
96.63
00.Off
11.On
See Terms and abbreviations (page 132).
Other [bit]
Off / uint32Starts, or selects a source that starts, the user data logger.User data logger start96.64
00.Off
11.On
See Terms and abbreviations (page 132).
Other [bit]
500us / uint16Selects the sampling interval for the factory data logger.
See section Warning/fault history and analysis (page 538).
Factory data logger
time level
96.65
500500 microseconds.500us
20002 milliseconds.2ms
1000010 milliseconds.10ms
No / uint16Disables/enables the adaptive program (if present). See
also section Adaptive programming (page 31).
Note: This parameter cannot be changed while the drive
is running.
Disable adaptive
program
96.70
0Adaptive program enabled.No
1Adaptive program disabled.Yes
10000000 / uint32
(Visible when user lock is open)
To change the current user pass code, enter a new code
into this parameter as well as 96.101 Confirm user pass
code. A warning will be active until the new pass code is
confirmed. To cancel changing the pass code, close the
user lock without confirming. To close the lock, enter an
invalid pass code in parameter 96.2 Pass code, activate
parameter 96.8 Control board boot, or cycle the power.
See also section User lock (page 104).
Change user pass
code
96.100
516 Parameters
