What to doCause
Event name /
Aux. code
Code
(hex)
Check that parameter 90.41 is not
changed to Estimate during the
routine.
Measured position status information
changed.
0006
Contact your local ABB representative.General autophasing failure.0007
Check that the selected mode
(parameter 21.13) is supported by the
motor type.
Selected mode not supported.0008
Contact your local ABB representative.(LV-Synchro) Standstill failure.0009
Check the auxiliary code. Check the
source of the fault corresponding to the
code:
Input phase loss detected by the IGBT
bridge.
Input phase
loss
3E00
1: Phase A
2: Phase B
4: Phase C
8: Phase cannot be detected
Check the AC fuses.
Check for input power supply imbalance.
Check the settings of parameters 35.61
and 35.62.
Calculated motor cable temperature has
exceeded warning limit.
Motor cable
overload
4000
Check the dimensioning of the motor
cable in regard to required load.
Check ambient temperature. If it exceeds
40 °C (104 °F), ensure that load current
Drive module temperature is excessive.Ambient
temperature
4100
does not exceed derated load capacity
of drive. See appropriate Hardware
manual.
Check drive module cooling air flow and
fan operation.
Check inside of cabinet and heatsink of
drive module for dust pick-up. Clean
whenever necessary.
Check proper cooling of the drive.Control board temperature is too high.Control board
temperature
4110
Check the auxiliary cooling fan.
Check ambient conditions.Estimated drive IGBT temperature is
excessive.
IGBT
overtemperature
4210
Check air flow and fan operation.
Check heatsink fins for dust pick-up.
Check motor power against drive power.
Check ambient temperature. If it exceeds
40 °C (104 °F), ensure that load current
Drive module temperature is excessive.Cooling4290
does not exceed derated load capacity
of drive. See appropriate Hardware
manual.
Check drive module cooling air flow and
fan operation.
Check inside of cabinet and heatsink of
drive module for dust pick-up. Clean
whenever necessary.
Check ambient conditions.Drive IGBT temperature is excessive.IGBT
temperature
42F1
Check air flow and fan operation.
Check heatsink fins for dust pick-up.
Check motor power against drive power.
Fault tracing 545
