ABB ACS880 - Page 549

What to doCause
Event name /
Aux. code
Code
(hex)
If the problem persists, contact your local
ABB representative.
Check that the value of 95.13 Reduced
run mode corresponds to the number of
Number of inverter modules detected
does not match the value of parameter
95.13 Reduced run mode.
Reduced run5695
inverter modules present. Check that the
modules present are powered from the
DC bus and connected by fiber optic
cables to the BCU control unit.
If all modules of the inverter unit are in
fact available (eg. maintenance work has
been completed), check that parameter
95.13 Reduced run mode is set to 0
(reduced run function disabled).
Contact your local ABB representative,
quoting the auxiliary code.
State feedback from output phases does
not match control signals.
PU state
feedback
5696
Charging
feedback
5697
•
Check the setting of 95.9 Switch
fuse controller. The parameter
• Incorrect parameter setting.
• The charging switch and DC switch
were operated out of sequence, or
should be enabled only if an xSFC
charging controller is installed.
a start command was issued before
the unit was ready.
• The normal power-up sequence is:
• Charging circuit fault.
1. Close charging switch.
• Brake circuit fault.
2. After charging finishes
(charging OK lamp lights),
close DC switch.
3. Open charging switch.
• Check the charging circuit.
With a frame R6i/R7i inverter
module, the auxiliary code “FA”
indicates that the charging
contactor status feedback does not
match the control signal.
With parallel-connected frame R8i
modules, the auxiliary code (format
XX00), “XX” specifies the affected
BCU control unit channel.
• Check the wiring and condition of
brake resistor.
Check power unit logic and firmware
compatibility.
Unidentified power unit logic fault.Unknown PU
fault
5698
Contact your local ABB representative.
Contact your local ABB representative,
quoting the auxiliary code.
Internal error.Internal SW
error
6000
FPGA version
incompatible
6181
• Reboot the control unit (using
parameter 96.8 Control board boot)
• Firmware and FPGA file version in
the power unit are incompatible.
or by cycling power. If the problem
• Update of power unit logic failed.
persists, contact your local ABB
representative.
Fault tracing 549
