Commissioning
108
1SVC 440 795 M1100
Proceed as follows:
Your CL-NET or your serial interface must be running
correctly.
X Press the OK button from the status display.
The first menu will appear.
X Press the í button.
This will display the TERMINAL mode menu item.
X Press the OK button.
The START MODE menu item will flash.
X Press the Í button.
Caution!
Data collision!
Proper operation is possible under the following
conditions.
The following applies:
If more than one display system is in Terminal mode in the
CL-NET, each display system must access a different
CL-NET station.
A device running in Terminal mode must not access any
two devices communicating with each other in Terminal
mode.
If a PLC with CL-SOFT or a display system with a serial
interface is active on a CL-NET station, this station must
not be accessed in Terminal mode via the CL-NET at the
same time.
PROGRAM... Æ
STOP å RUN
PARAMETER
SET CLOCK... æ
STOP å RUN Æ
PARAMETER
SET CLOCK...
TERMINAL MODE..æ
STATION ID: 0
START MODE
