ABB CL Series User Manual

Mounting
31
1SVC 440 795 M1100
Figure: 5: Fitting the CL-LAD.FD001 protective cover
a Protective cover CL-LAD.FD001
b Display module
X Fit the protective cover over the display module.
a
b
Caution!
Ensure that the CL-LAD.FD001 protective cover is fitted in
the groove all round the display module.
Otherwise a proper seal cannot be guaranteed and
particles may enter underneath the protective cover.
This may cause malfunctions in the keypad.
In food industry applications, there is the risk of bacteria
building up underneath the protective cover.
