Mounting
37
1SVC 440 795 M1100
Figure: 13: Screw fastening the display module
X Screw fasten the display module
The tightening torque must be between 1.2 and 2 Nm
Figure: 14: Rear of mounted display module
Removing the display module (flush mounting)
X Unscrew the fixing element and remove the display module.
2 x
h
Ensure that the correct torque is used. If the tightening
torque is too low or high, this may impair the seal.
