Commissioning via ABB-free@home®
Product manual 2CKA00xx73xxxxx
101
9.3 Specifying or editing functions (buttons)
The settings are made via the panel configuration of the Web-based user
interface of the System Access Point.
The ABB SmartTouch
®
has an automatic configuration. At an existing IP connection all located
devises are synchronized automatically with the ABB SmartTouch
®
. This allows all devices to
be switched via the ABB SmartTouch
®
without having to be added manually beforehand. One
page of the panel can be configured manually in addition. With a connection via Twisted Pair
the automatic configuration is cancelled and the panel pages must be configured manually.
In the panel configuration the buttons of the device can be freely equipped. All panels installed
in the system can be selected.
Only panels are listed that have been previously positioned on the floor plan under
commissioning step "Allocation"!
The allocated actuator channels can be positioned on the panel via drag-and-drop from the list
view. After the confirmation the configuration is taken over and becomes visible on the device
after a few seconds.
9.3.1 Creating functions
There are two options for accessing the panel configuration. First you need to change to the
menu provided. To do this, proceed as follows:
Version 1
1. Tap on the toothed wheel [1] (menu devices, scenes and groups) at the left edge of the
screen.
– The "Building plan" opens.
2. Tap on the panel whose information you want to edit.
– A new window with the information about the respective panel opens.
3. Under menu item "Panel configuration" tap on the "Configure" button.
– The "Panel configuration" opens.
