KNX control elements and application parameters
Control element: "Dimmer slider"
Product manual 2CKA00xx73xxxxx
125
10.4.7 Display value in control element
Options: Deactivated
Activated
The parameter is used to specify whether the dimming value is displayed in the control element.
– No: No display. No additional parameters available.
– Yes: The following parameters are displayed:
Status of dimming value is controlled by a separate object:
Options: Deactivated
Activated
The brightness value signalled by the dimmer slider can be displayed via a separate object.
An additional 1-bit communication object "Status value" is enabled. The displayed value
does not originate from the control element. The value is received via a separate feedback
object.
Unit:
Options: <Text>
The parameter is used to enter the unit or the unit sign with which the value is displayed in
the control element.
The length of the text is limited to 20 characters.
