KNX control elements and application parameters
Control element "Audio control"
Product manual 2CKA00xx73xxxxx
178
10.14.9 Use of button for mute
Options: Deactivated
Activated
– Deactivated: No mute button is enabled. No additional parameters available.
– Activated: The mute button is enabled. The following supplementary parameter is available:
Object type mute:
Options: 1 bit
1-byte value [0 - 255]
The parameter is used to specify the size of the communication object for sending
telegrams.
– 1 bit: Commands of a mute button are sent with 1 bit (0 or 1). The following
supplementary parameters are available:
Value for mute:
Options: 0
1
The parameter is used to send the command for "Mute" with "0" or "1".
Value for unmute:
Options: 0
1
The parameter is used to send the command for "Unmute" with "0" or "1".
- 1-byte value [0 - 255]: The value of a mute button is sent as 1-byte value without a sign.
The following supplementary parameters are available:
Value for mute:
Options: Setting option from 0 - 255
The parameter is used to send the value for "Mute" as absolute value.
Value for unmute:
Options: Setting option from 0 - 255
The parameter is used to send the value for "Unmute" as absolute value.
