KNX control elements and application parameters
Application "Presence simulation"
Product manual 2CKA00xx73xxxxx
197
10.21 Application "Presence simulation"
10.21.1 Use of presence simulation
Options: Deactivated
Activated
The parameter is used to specify whether presence simulation is displayed.
– Disabled: No display in the panel. No additional parameters available.
– Activated: An entry on the application page "Time programs" is displayed for activating and
deactivating the function on the panel. The following parameters are displayed:
10.21.2 Page PIN-protected
Options: Deactivated
Activated
The parameter is used to specify whether the presence simulation application is protected by a
PIN code.
– Deactivated: The application is not protected.
– Activated: The application can only be activated or deactivated by entering a PIN code
(replay or record). The following supplementary parameter is available:
PIN code level:
Options: Level 1
Level 2
Level 3
Level 4
Level 5
The parameter is used to specify the PIN code level for the application.
Notice
Details about the PIN code, see chapter 8.6.1 “Basic settings (system
settings) of the panel“ on page 56.
10.21.3 Enable export
Options: Deactivated
Activated
The parameter is used to specify that the recorded telegrams can be exported under the fixed
file name in CSV format.
– Deactivated: No export. No additional parameters available.
– Activated: The following parameter appears:
File name [.CSV]:
Options: <Text>
The parameter is used to change the file name of the export file.
