10 KNX control elements and application parameters
10.1 "Switch" control element
10.1.1 Name of the control element
Options: <Name>
Naming the switch control element, e.g. name of the lamp that is to be switched.
The length of the name is limited to 36 characters.
10.1.2 Size of the button
Options: 1 column
2 columns
The parameter is used to specify whether the control element occupies one column (one button
or control frame) or two columns (two buttons or control frames).
10.1.3 Type of switch
Options: Switchover
Press/release
Short/long
Notice
The selection depends on the type of switch.
The parameter is used to specify the signals (values) the switch sends to the KNX bus when it
is operated.
– Switchover: No additional parameters available.
– Pressing/releasing: Pressing = value 1; releasing = value 2.
The following supplementary parameters are available, :
– Object type value 1: When actuated (pressing) the control element sends telegrams via
the associated communication object. This parameter is used to specify the size of the
communication object.
– Object type value 2: When actuated (releasing) the control element sends telegrams via
the associated communication object. This parameter is used to specify the size of the
communication object.
