ABB SmartTouch i-bus KNX User Manual

Technical data
Product manual 2CKA00xx73xxxxx
│
28
5 Technical data
Designation Value
Display resolution 1280 x 800 pixel (HD)
Aspect ratio 16:9
Colour resolution 16 million colours
Display size 25.4 cm (10")
Viewing angle:
■
horizontal:
■
vertical:
75°
75°
Backgroung illumination LED
Maximum brightness ±240 cd/m
2
Service life
±20 000 h
(at maximum brightness of > 125cd/m
2
)
Touch technology
– Calibration:
Capacitive
Automatically
Degree of protection IP20
Single-wire clamps 2 x 1.0 mm
2
- 2 x 1.4 mm
2
Fine-wire clamps 2 x 0.5 mm
2
- 2 x 1.8 mm
2
Nominal voltage 24 VDC
Mains supply 20 V - 32 V DC
ABB-Welcome
®
/
ABB-free@home
®
bus voltage
21 V - 32 V DC
KNX bus voltage 21 V - 32 V DC
Energy consumption (power input)
■
maximum
■
standby:
< 12 W
< 1.5 W
KNX bus connection terminal 0.6 mm - 0.8 mm single-wire
WLAN frequency ranges 2400 - 2485 MHz
WLAN transmitting power Max. 20 dBm (100 mW)
WLAN standard IEEE 802.11 a/b/g/n
Micro SD card (SDXC, SDHC)
max. 128 GB,
Card slot for SD card,
Formatting FAT32 or exFAT
Operating temperature 0°C - +45°C
Storage temperature -20°C - +70°C
Dimensions 254.6 mm x 180.2 mm x 17.4 mm
Commissioning
Parameter setting: Programming (KNX)
ETS 6 (from ETS 5.x) and touch DCA
Via KNX bus or micro SD card
Parameter setting: (free@home) Via SAP-S-1-84 (no SD card required)
Table 3: Technical data
