KNX control elements and application parameters
Control element "Audio control"
Product manual 2CKA00xx73xxxxx
180
10.14.11 Use of ON/OFF button
Options: Deactivated
Activated
– Deactivated: No ON/OFF button is enabled. No additional parameters available.
– Activated: The ON/OFF button is enabled. The following supplementary parameter is
available:
Object type ON/OFF button:
Options: 1 bit
1-byte value [0 - 255]
The parameter is used to specify the size of the communication object for sending
telegrams.
– 1 bit: Commands of an ON/OFF button are sent with 1 bit (0 or 1). The following
supplementary parameters are available:
Value for ON:
Options: 0
1
The parameter is used to send the command for "ON" with "0" or "1".
Value for OFF:
Options: 0
1
The parameter is used to send the command for "OFF" with "0" or "1".
- 1-byte value [0 - 255]: The value of an ON/OFF button is sent as 1-byte value without a
sign. The following supplementary parameters are available:
Value for ON:
Options: Setting option from 0 - 255
The parameter is used to send the value for "ON" as absolute value.
Value for OFF:
Options: Setting option from 0 - 255
The parameter is used to send the value for "OFF" as absolute value.
10.14.12 Enable 1-bit communication object "Disable"
Options: Deactivated
Activated
There is the option of temporarily disabling the function via an additional communication object
"Disable".
