KNX control elements and application parameters
"Dimmer" control element
Product manual 2CKA00xx73xxxxx
120
10.3.5 Icon for On / icon for Off
Options: Icon for On
Icon for Off
The parameter is used to set the icon that is to be displayed when the light is switched on or off.
– Icon for On: The selected icon is displayed when the light is switched on.
– Icon for Off: The selected icon is displayed when the light is switched off.
Notice
The parameter can only be set when parameter "Icon type" is set on "User-
defined".
10.3.6 Position for dim up icon
Options: Left
Right
The parameter is used to set whether the icon for "Dim up" is positioned on the right or left side.
10.3.7 Icon for dimming up / icon for dimming down
Options: Icon for dimming up
Icon for dimming down
The parameter is used to set the icon that is to be displayed when the light is dimmed up or
down.
– Icon for dimming up: The selected icon is displayed when the light is dimmed up.
– Icon for dimming down: The selected icon is displayed when the light is dimmed down.
10.3.8 Status control element (icon) is operated via a separate object
Options: No
Yes
An additional 1-bit communication object "Status" is enabled via the parameter.
When the object has been enabled, the status display of the control element indicates the
current status of the object. The feedback object can ensure that the correct status is always
displayed.
If an actuator has a separate feedback object, this additional object can check whether the
actuator has switched. For this the feedback object of the actuator must be connected with the
feedback object of the button via a common group address (Action).
If the status display is not activated via a feedback object, the control element always changes
to the other status when actuated.
10.3.9 Status of dimming value is controlled by a separate object
Options: No
