KNX control elements and application parameters
Control element "Fan switch"
Product manual 2CKA00xx73xxxxx
140
10.8.5 Icon type
Options: Default
User-defined
The parameter is used to set whether a standard icon or a self-selected icon ("user-defined") is
displayed.
The following supplementary parameters are available for all options:
Position of the Up icon:
Options: Left
Right
The parameter is used to specify whether the icon for "Up" (Switching the fan speed level up) is
positioned on the right or left side of the control element.
Icon for Up:
Options: <Selection of an icon from the list>
The parameter is used to select the icon that is to be displayed in the control element for
switching the fan speed level up.
Icon for Down:
Options: <Selection of an icon from the list>
The parameter is used to select the icon that is to be displayed in the control element for
switching the fan speed level down.
The following parameter can only be set when parameter "Icon type" is set on "User-defined".
Icon for On:
Options: <Selection of an icon from the list>
The parameter is used to select the icon that is to be displayed when the fan is switched on.
The following parameter can only be set when parameter "Icon type" is set on "User-defined"
and the parameter "Deactivation of switch-off option" is set on "No".
Icon for Off:
Options: <Selection of an icon from the list>
The parameter is used to select the icon that is to be displayed when the fan is switched off.
10.8.6 Telegram is repeated every [sec.]:
Options: Setting option from 0.25 - 1.25 seconds
The parameter is used to specify the space of time between two telegrams.
