KNX control elements and application parameters
Operation of "RGBW" control element“
Product manual 2CKA00xx73xxxxx
127
10.5 Operation of "RGBW" control element“
10.5.1 Name of the control element
Options: <Name>
Naming the switch control element, e.g. name of the lamp that is to be switched.
The length of the name is limited to 36 characters.
10.5.2 Function of the control element
Options: Not defined (grey)
Light (yellow)
Blind (blue)
Temperature (orange)
Scene (magenta)
Alarm (red)
Feedback (green)
The parameter is used to specify the colour of the function line.
"Light (yellow)" has been made available for functions of this type.
10.5.3 Display value in control element
Options: Deactivated
Activated
The parameter is used to specify whether the RGBW value is displayed in the control element.
10.5.4 Type of colour/white lamp
Options: RGB
RGB+W
RGB+WW/CW
WW/CW
The parameter is used to specify how the colour activation is to be controlled. Corresponding
sliders will be displayed in the control element. The type of colour control depends on the type
of lamp. Specific settings can be made for the lamps. For example, the colours can be changed
or the warm-white component can be adjusted.
– RGB: Used for RGB lamp. The following supplementary parameter is available:
Switching On/Off via:
Options: Switch object
RGB feedback signal
