Product Overview
Product manual 2CKA00xx73xxxxx
25
4.1 Scope of supply
The panel is included in the scope of supply.
The enclosed bus connection terminal serves for the connection with the ABB i-bus
®
KNX
and/or the ABB-Welcome
®
bus. The connection with the ABB-free@home
®
System Access
Point is made via WLAN and/or the ABB-free@home
®
bus.
The special Surface-mounted mounting frame (ST/A10.1-xxx) and the associated Flush-
mounted installation box (6136/07 UP-500; windproof) are not included in the scope of supply.
The necessary power supplies (e.g. CP-D 24/2.5) are also not included in the scope of supply.
Separate power supplies are only required in combination with ABB i-bus
®
KNX and ABB-
free@home
®
.
4.2 Additional necessary components
■
Power adapter for the 20 - 32 V DC (SELV) auxiliary power supply (power supply of device)
or the central control system ABB-Welcome
®
(no additional power supply is necessary in
this case).
■
Associated flush-mounted installation box or surface-mounted mounting frame (if the device
is not mounted on the associated flush-mounted installation box).
4.3 Overview of types
Article no. Product name Colour Display diagonal
ST/U10.1.1-811 ABB SmartTouch
®
B/stainless
Stainless
steel
25.4 cm (10“)
ST/U10.1.1-825 ABB SmartTouch
®
B/stainless
Stainless
steel
25.4 cm (10“)
ST/U10.2.1-811 ABB SmartTouch
®
W/graphite Graphite 25.4 cm (10“)
ST/U10.2.1-825 ABB SmartTouch
®
B/graphite Graphite 25.4 cm (10“)
ST/U10.3.1-811 ABB SmartTouch
®
W/satin gold Gold 25.4 cm (10“)
ST/U10.3.1-825 ABB SmartTouch
®
B/satin gold Gold 25.4 cm (10“)
ST/U10.4.1-811 ABB SmartTouch
®
W/rose gold Roségold 25.4 cm (10“)
ST/U10.4.1-825 ABB SmartTouch
®
B/rose gold Roségold 25.4 cm (10“)
ST/A10.1-811 ABB SmartTouch
®
SM Frame W White 25.4 cm (10“)
ST/A10.1-825 ABB SmartTouch
®
SM Frame B Black 25.4 cm (10“)
Table 1: Overview of types
