KNX control elements and application parameters
"Display" control element
Product manual 2CKA00xx73xxxxx
169
Minimum object value:
Options: Setting option depends on the selected object type.
The parameter is used to specify the smallest value that is sent via telegrams to the display
element.
Any value within the limits specified by the object type and its value range can be entered.
Maximum object value:
Options: Setting option depends on the selected object type.
The parameter is used to specify the largest value that is sent via telegrams to the display
element.
Any value within the limits specified by the object type and its value range can be entered.
Displayed minimum value:
Options: Setting option depends on the selected object type.
The parameter is used to specify the smallest value that is displayed in the display element.
Any value within the limits specified by the object type and its value range can be entered. The
value can deviate from the setting of parameter "Minimum object value".
Displayed maximum value:
Options: Setting option depends on the selected object type.
The parameter is used to specify the largest value that is displayed in the display element.
Any value within the limits specified by the object type and its value range can be entered. The
value can deviate from the setting of parameter "Maximum object value".
10.13.11 Type of display element — Round measurement display
Note
For option "Round measurement display" of parameter "Type of display element"
the same supplementary parameters are available, such as for option "Linear
measurement display", see chapter 10.13.10 “Type of display element — Linear
measurement display — Object type“ on page 168.
