KNX control elements and application parameters
Control element: "Dimmer slider"
Product manual 2CKA00xx73xxxxx
124
10.4.5 Icon for On / icon for Off
Options: Icon for On
Icon for Off
The parameter is used to set the icon that is to be displayed when the light is switched on or off.
– Icon for On: The selected icon is displayed when the light is switched on.
– Icon for Off: The selected icon is displayed when the light is switched off.
Notice
The parameter can only be set when parameter "Icon type" is set on "User-
defined".
10.4.6 Status control element (icon) is operated via a separate object
Options: Deactivated
Activated
An additional 1-bit communication object "Switch status" is enabled via the parameter.
When the object has been enabled, the status display of the control element indicates the
current status of the object. The feedback object can ensure that the correct status is always
displayed.
If an actuator has a separate feedback object, this additional object can check whether the
actuator has switched. For this the feedback object of the actuator must be connected with the
feedback object of the button via a common group address (Action).
If the status display is not activated via a feedback object, the control element always changes
to the other status when actuated.
