ABB SmartTouch i-bus KNX User Manual

KNX control elements and application parameters
"Switch" control element
Product manual 2CKA00xx73xxxxx
│
109
Transmitted value 1 / value 2 [scene number]:
Options: Setting option from 0 - 64
Calling up or storing scenes
– 0 - 64: Entry of scene number.
– Calling up or storing scenes: The parameter is used to specify whether the scene is
called up or stored (the scene number is sent with the additional information that the
scene is to be stored).
– RTC operating mode: After actuating the control element the device switches to the
parameterized operating mode. The following supplementary parameter is available:
Sent value 1 / value 2 [RTC operating mode]:
Options: Auto
Comfort
Standby
ECO
Frost/heat protection
– Temperature: After the control element is actuated, the device sends the parameterized
temperature value. The following supplementary parameter is available:
Transmitted value 1 / value 2 [temperature]:
Options: Setting option from 16 - 31
– 2-byte value [-32768 - +32767]: A value is sent as 2-byte value with a sign, e.g. an actuating
value or a time difference. The following supplementary parameter is available:
Sent value 1 / value 2 [-32768 - 32767]:
Options: Setting option from -32768 - +32767
– 2-byte value [0 - 65535]: A value is sent as 2-byte value without a sign, e.g. an actuating
value or a time interval. The following supplementary parameter is available:
Sent value 1 / value 2 [0 - 65535]:
Options: Setting option from 0 - 65535
– 2-byte floating point: A value is sent as 2-byte floating point value, e.g. a temperature value,
a time duration, a performance or a consumption value. The following supplementary
parameter is available:
Sent value 1 / value 2 [-671088.64 - 670760.96]:
Options: Setting option from -671088.64 - +670760.96
– 4-byte value [-2147483648 - 2147483647]: A value is sent as 4-byte value with a sign, e.g.
an actuating value or a time difference. The following supplementary parameter is available:
Sent value 1 / value 2 [-2147483648 - 2147483647]:
Options: Setting option from -2147483648 - 2147483647
– 4-byte value [0 - 4294967295]: A value is sent as 4-byte value without a sign, e.g. an
actuating value. The following supplementary parameter is available:
Sent value 1 / value 2 [0 - 4294967295]:
Options: Setting option from 0 - 4294967295
