KNX control elements and application parameters
Application "Fault and alarm messages" - Settings of the individual messages
Product manual 2CKA00xx73xxxxx
191
Repeat of alarm as long as it is active:
Options: Deactivated
Activated
– Deactivated: In the active state the acoustic alarm signal is not repeated. No additional
parameters available.
– Activated: The signal tone is repeated as long as the alarm is active. The following
supplementary parameter is available:
Repeat time [min.]:
Options: Setting option from 1 - 60
The parameter is used to specify the cycle (in minutes) with which the alarm is repeated.
– 14 byte: A text is displayed and sent when acknowledging the alarm. The following
supplementary parameters are available:
Sending text at acknowledgement:
Options: Deactivated
Activated
– Deactivated: No text is sent at acknowledgement. No additional parameters available.
– Activated: The text that was specified via the following parameters is sent at
acknowledgement:
Text at acknowledgement:
Options: <Text>
The parameter is used to specify the text that is sent at acknowledgement of the alarm.
The length of the text is limited to 60 characters.
Acoustic alarm signal:
Options: Deactivated
Activated
The parameter is used to specify whether the signal tone specified under the global settings
is played see chapter 10.18 “Application "Fault and alarm messages" - Global settings“ on
page 187.
– Deactivated: No acoustic alarm signal. No additional parameters available.
– Activated: The signal tone is played at an alarm signal. The following supplementary
parameter is available:
Duration of audio signal [min.]:
Options: Setting option from 1 - 60
The parameter is used to specify how long the specified signal tone is to be played (in
minutes).
