KNX control elements and application parameters
Application "Logical functions"
Product manual 2CKA00xx73xxxxx
201
Options: 1 bit
1 byte
The parameter is used to specify whether the input object consists of a 1-bit value (0/1) or a
1-byte value (0 - 255). See the explanation above.
Notice
How many "Object type input x" parameters are displayed depends on the
setting of the "Number of input objects" parameter.
Initial value input x:
Options: Initialised with 0
Initialised with 1
See the explanation above.
Notice
How many "Initial value input x" parameters are displayed depends on the
setting of the "Number of input objects" parameter.
Logic input x:
Options: Normal
Inverse
See the explanation above.
Notice
How many "Logic input x" parameters are displayed depends on the
setting of the "Number of input objects" parameter.
Object type output:
Options: 1 bit
1 byte
The parameter is used to specify whether the output object consists of a 1-bit value (0/1) or
a 1-byte value (0 - 255). See the explanation above.
Sending output objects:
Options: With each input telegram
With a change of the output object
The parameter is used to specify when the output object is sent.
Value of the output object at logic true:
Options: Output is set on 1
Defined via output default value true
The parameter is used to specify the value of the output object in the logic status "True".
See the explanation above.
