KNX control elements and application parameters
Application "Logical functions"
Product manual 2CKA00xx73xxxxx
203
Start requirements:
Options: 1 bit
1 byte
See the explanation above.
– 1 bit: The following parameter appears:
Start command:
Options: OFF - telegram
ON - telegram
See the explanation above.
– 1 byte: The following parameter appears:
Start command:
Options: Setting options from 0 - 255
See the explanation above.
Telegram delay:
Options: Setting option from 200 ms - 10 seconds
The parameter is used to set the time delay for telegrams.
Used outputs:
Options: Setting options from 1 - 10
The parameter is used to set the number of output objects to be used in the "Multiplier"
application.
Object type output x:
Options: 1 bit
1 byte [0 - 100%]
The parameter is used to specify whether the output object consists of a 1-bit value (0/1) or
a 1-byte value (in percent).
Notice
How many "Object type output x" parameters are displayed depends on
the setting of the "Outputs used" parameter.
– 1 bit: The following parameter appears:
Value of output x:
Options: 0
1
This parameter is used to specify the value the communication object has on output x.
– 1 byte [0 - 100%]: The following parameter appears:
