ABB SmartTouch i-bus KNX User Manual

KNX control elements and application parameters
Application "Logical functions"
Product manual 2CKA00xx73xxxxx
│
210
Staircase light period [hh:mm:ss]:
Options: Setting options from 00:00:01 - 12:00:00
The time of the switch-off delay (hh:mm:ss) is set via the parameter.
Use of switch-on delay time:
Options: Deactivated
Activated
The parameter is used to specify whether the staircase light is switched with a switch-on
delay.
– Deactivated: No additional parameters available.
– Activated: The following parameter appears:
Switch-on delay time [hh:mm:ss]:
Options: Setting options from 00:00:01 - 12:00:00
The time of the switch-off delay (hh:mm:ss) is set via the parameter.
Retriggerable:
Options: Deactivated
Activated
The parameter is used to specify whether the delay times are reset or restarted with
renewed switching of the staircase light.
– ON/OFF delay: The following parameters are displayed:
Use of switch-on delay time:
Options: Deactivated
Activated
The parameter is used to specify whether the time function is switched with a switch-on
delay.
– Deactivated: No additional parameters available.
– Activated: The following parameter appears:
Switch-on delay time [hh:mm:ss]:
Options: Setting options from 00:00:01 - 12:00:00
The time of the switch-on delay (hh:mm:ss) is set via the parameter.
Use of switch-off delay time:
Options: Deactivated
Activated
The parameter is used to specify whether the time function is switched with a switch-off
delay.
– Deactivated: No additional parameters available.
– Activated: The following parameter appears:
Switch-off delay time [hh:mm:ss]:
Options: Setting options from 00:00:01 - 12:00:00
The time of the switch-off delay (hh:mm:ss) is set via the parameter.
