ABB SmartTouch i-bus KNX User Manual

Communication objects
Application "Internal RTC"
Product manual 2CKA00xx73xxxxx
│
255
Name Object function Length Data type Flags
K L S U A
Fault and alarm messages
Signal tone volume Input 1 byte
[5.001]
Percent
(0 - 100%)
K - S - A
Raise/lower signal tone
volume
Input 1 byte
[3.007]
Dimmer step
K - S - A
Confirm all [1 bit] Input 1 bit
[1.016]
Confirmation
K - S - A
Message [14 bytes]
Input/
Output
14 bytes
[16.001]
Character
(ISO 8859-1)
K - S U A
Message [1bit]
Input/
Output
1 bit
[1.005]
Alarm
K - S U A
Confirm message
[14 bytes]
Output 14 bytes
[16.001]
Character
(ISO 8859-1)
K - S U A
Confirm message
[1bit]
Input/
Output
1 bit
[1.016]
Confirmation
K - S U A
Scene actuator
Object 1 [send] Output 1 bit
[1.001]
Switching
K - - U -
Object 1 [receive] Input 1 bit
[1.001]
Switching
K - S U A
Object 2 [send] Output 1 bit
[1.001]
Switching
K - - U -
Object 2 [receive] Input 1 bit
[1.001]
Switching
K - S U A
Object 3 [send] Output 1 bit
[1.001]
Switching
K - - U -
Object 3 [receive] Input 1 bit
[1.001]
Switching
K - S U A
Object 4 [send] Output 1 bit
[1.001]
Switching
K - - U -
Object 4 [receive] Input 1 bit
[1.001]
Switching
K - S U A
Object 5 [send] Output 1 bit
[1.001]
Switching
K - - U -
Object 5 [receive] Input 1 bit
[1.001]
Switching
K - S U A
Object 6 [send] Output 1 bit
[1.001]
Switching
K - - U -
Object 6 [receive] Input 1 bit
[1.001]
Switching
K - S U A
Object 7 [send] Output 1 bit
[1.001]
Switching
K - - U -
Object 7 [receive] Input 1 bit
[1.001]
Switching
K - S U A
Object 8 [send] Output 1 bit
[1.001]
Switching
K - - U -

