ABB SmartTouch i-bus KNX User Manual

Communication objects
Application "Internal RTC"
Product manual 2CKA00xx73xxxxx
│
266
Name Object function Length Data type
Fl
a
g
s
K L S U A
HSV value [3 bytes] Output 3 bytes
[232.600]
RGB value 3x
(0 - 255)
K - - U -
Status value RGB [3 bytes] Input 3 bytes
[232.600]
RGB value 3x
(0 - 255)
K - S - A
Brightness value Output 1 byte
[5.010]
Counting pulses
(0 - 255)
K - - U -
Brightness status value Input 1 byte
[5.010]
Counting pulses
(0 - 255)
K - S - A
Temperature value Output 2 bytes
[7.600]
Absolute colour
temperature
(K)
K - - U -
Temperature status value Input 2 bytes
[7.600]
Absolute colour
temperature
(K)
K - S - A
Blind
Moving UP/DOWN
Input/
Output
1 bit
[1.008]
Up/Down
K - S U A
Stop / slat adjustment
Input/
Output
1 bit
[1.008]
Up/Down
K - S U A
Move to position
Input/
Output
1 byte
[5.001]
Percent
(0 - 100%)
K - S U A
Slat position
Input/
Output
1 byte
[5.001]
Percent
(0 - 100%)
K - S U A
Position status Input 1 bit
[1.002]
Boolean
K - S - A
Upper end position status Input 1 bit
[1.002]
Boolean
K - S - A
Bottom end position status Input 1 bit
[1.002]
Boolean
K - S - A
Height status [0 - 100%] Input 1 byte
[5.001]
Percent
(0 - 100%)
K - S - A
Slat status [0-100%] Input 1 byte
[5.001]
Percent
(0 - 100%)
K - S - A
Height status [0 - 255] Input 1 byte
[5.010]
Counting pulses
(0 - 255)
K - S - A
Slat status [0-255] Input 1 byte
[5.010]
Counting pulses
(0 - 255)
K - S - A

