ABB SmartTouch i-bus KNX User Manual

Communication objects
Application "Internal RTC"
Product manual 2CKA00xx73xxxxx
│
272
Name Object function Length Data type Flags
K L S U A
Voltage Input 2 bytes
[9.020]
Voltage (mV)
K - S - A
Current Input 2 bytes
[9.021]
Current (mA)
K - S - A
Frequency Input 4 bytes
[14.033]
Frequency (Hz)
K - S - A
Power Input 2 bytes
[9.024]
Power (kW)
K - S - A
Energy? Input 4 bytes
[13.010]
Effective work
(Wh)
K - S - A
Power factor Input 4 bytes
[14.033]
Power factor
(cosΦ)
K - S - A
Phase angle Input 4 bytes
[14.055]
Phase angle(°)
K - S - A
Gas volume Input 4 bytes
[12.1201]
Volume (m
3
)
K - S - A
Water quantity Input 4 bytes
[12.1201]
Volume (m
3
)
K - S - A
Flow-through volume Input 4 bytes
[13.002]
Flow-through
volume(m
3
/h)
K - S - A
Block Input 1 bit
[1.002]
Boolean
K - S - A
Audio control
title Input 14 bytes
Sign
(ASCII)
K - S - A
Artist Input 14 bytes
Sign
(ASCII)
K - S - A
Album Input 14 bytes
Sign
(ASCII)
K - S - A
Play
Input/
Output
1 bit
[1.001]
Start/Stop
K - S U A
Pause
Input/
Output
1 bit
[1.001]
Enable
K - S U A
Forward
Input/
Output
1 bit
Step
(0 - 100%)
K - S U A
Backwards
Input/
Output
1 bit
Step
(0 - 100%)
K - S U A
Tone off
Input/
Output
1 bit
[1.001]
Enable
K - S U A
Shuffle
Input/
Output
1 bit
[1.001]
Enable
K - S U A
Retry
Input/
Output
1 bit
[1.001]
Enable
K - S U A
Volume
Input/
Output
1 byte
[5.001]
Percent
(0 - 100%)
K - S U A

