Page #312 background imageLoading...
Page #312 background image
Operation
Product manual 2CKA00xx73xxxxx
312
Setting the screen saver
A screen saver can be activated if the display is not used. Here you can select between a clock,
slideshow and weather. If a micro SD card (SDHC) with suitable pictures is in the device, select
a screen saver via the drop-down menu. If there are several pictures on the micro SD card
(SDHC), they are displayed as a slide show.
1. Specifying the type of the screen saver.
2. Then, if necessary, a time delay up to the triggering of the screen saver can be set.
3. Then, if necessary, a time delay up to the switch-off of the display can be set.
Activate the checkbox additionally when the display is to switch off already after a brief
period.
Notice
If the weather display is used as screen saver, the data are called up out of the
Internet. The weather data are called up via MyBuildings.
Picture requirements for slideshow
The pictures must be stored on the micro SD card (SDHC) on the first level
in the "Picture" directory.
The maximum permissible size of a picture is 3 MB.
The supported format is "jpg".
