ADVANTEST R3132 Series User Manual

R3132 Series Spectrum Analyzer Operation Manual
2.4.2 Saving or Recalling Data
2-109
Figure 2-109 Display for Selecting the Data to be Saved
5. Press Save Item.
The Save menu is closed.
Choosing the file name
6. Select the file name you want to save your data under using the data knob.
When the file is being saved to RAM, the file names appear as REG00 or above.
For floppy disks, the file names start from FILE00 and continue with 01, 02 etc.
NOTE: In the above example a file number is used instead of a file name, but you
can use an arbitrary file name if desired. For information on how to set file
names, refer to Section 2.4.5.
Saving data
7. Press Save.
The data has now been saved.

ADVANTEST R3132 Series Specifications

General

Brand	ADVANTEST
Model	R3132 Series
Category	Measuring Instruments
Language	English
