R3132 Series Spectrum Analyzer Operation Manual

1.6 Cleaning, Storing and Transporting the R3132 Series Spectrum Analyzer

1-13

1.6 Cleaning, Storing and Transporting the R3132 Series Spectrum Analyzer

1.6.1 Cleaning

Remove dust from the outside of the spectrum analyzer by wiping or brushing the surface with a soft cloth

or small brush. Use a brush to remove dust from around the panel keys. Hardened dirt can be removed by

using a cloth which has been dampened in water containing a mild detergent.

CAUTION:

1. Do not allow water to get inside the spectrum analyzer.

2. Do not use organic cleaning solvents, such as benzene, toluene, xylene, acetone or similar compounds, since

these solvents may damage the plastic parts.

3. Do not use abrasive cleaners.

• Cleaning the Display Filter

Normally cleaning the display filter from the front should be sufficient. However, if necessary, the fil-

ter itself can be detached from the spectrum analyzer by removing the two screws on the front. Clean

the backside of the filter with a soft cloth.

CAUTION: Do not touch the LCD display with your finger when the filter has been removed.

Figure 1-8 Removing the Display Filter

Remove the two screws

to detach the filter

from the spectrum analyzer.
