R3132 Series Spectrum Analyzer Operation Manual
4.2.9 GPIB Command Codes
4-38
Table 4-12 Auto Tune
Table 4-13 Counter
Table 4-14 Power (1 of 3)
Function Listener Code
Talker Request
Code Output Format
Auto Tune TN ––– –––
Function Listener Code
Talker Request
Code Output Format
Resolution : 1kHz
: 100Hz
:10Hz
:1Hz
CN0
CN1
CN2
CN3
CN? 0:1kHz
1:100Hz
2:10Hz
3:1Hz
Counter ON
OFF
COUNT ON
COUNT OFF
COUNT? 0:OFF
1:ON
Counter value ––– CNRES? Frequency
Function Listener Code
Talker Request
Code Output Format
Channel Power PWCH PWCH?
PWCHON?
Level
0:OFF
1:ON
Parameter setup
Default
Manual
Define → Default
PWCHST USR
PWCHST MNL
PWCHST DEF
PWCHST? 0:(Unused)
1:Default
2:Manual
Total Power PWTOTAL PWTOTAL?
PWTOTALON
?
Level
0:OFF
1:ON
Average Power PWAVG PWAVG?
PWAVGON?
Level
0:OFF
1:ON
Average time PWTM * PWTM? Integer (1 to 999)
Window center position WLX * WLX? Frequency
Window width WDX * WDX? Frequency
Power OFF PWM ––– –––
OBW Execution
OBW OFF
OBW [ON]
OBW OFF
OBWON? 0:OFF
1:ON
OBW measurement value ––– OBW? Center,OBW
OBW % OBWPER * OBWPER? OBW%
OBW real-time execution OBWEXE ––– –––
