R3132 Series Spectrum Analyzer Operation Manual
5.4.4 Linearity Error (External Mixer Mode)
5-118
Table 5-32 Relationship Between the Frequency Range and Signal Generator Frequency Setting
(Used on the R3132 Series)
Range
Signal generator
1st Frequency
Signal generator
2nd Frequency
1 kHz/ 421.396 MHz 421.404 MHz
2.5 kHz/ 421.39 MHz 421.41 MHz
5 kHz/ 421.38 MHz 421.42 MHz
10 kHz/ 421.36 MHz 421.44 MHz
25 kHz/ 421.3 MHz 421.5 MHz
50 kHz/ 421.2 MHz 421.6 MHz
100 kHz/ 421 MHz 421.8 MHz
250 kHz/ 420.4 MHz 422.4 MHz
500 kHz/ 423.4 MHz 419.4 MHz
1 MHz/ 425.4 MHz 417.4 MHz
2.5 MHz/ 431.4 MHz 411.4 MHz
5 MHz/ 441.4 MHz 401.4 MHz
10 MHz/ 461.4 MHz 381.4 MHz
25 MHz/ 521.4 MHz 321.4 MHz
50 MHz/ 621.4 MHz 221.4 MHz
