5.2.15 Second Harmonic Distortion
5-55
5.2.15 Second Harmonic Distortion
A synthesized signal generator and low pass filter provide the signal for measuring second harmonic dis-
tortion. The low pass filter eliminates any harmonic distortion originating at the signal source.
The R3132 series frequency response is calibrated.
The signal generator is phase-locked to the spectrum analyzer’s 10 MHz reference.
Test will be done the points of 1.5 GHz and 1.9 GHz as fundamental signal.
To measure second harmonic distortion, use Fixed Marker in Delta Marker function.
Specification:
Apply for R3132
≤ -70 dBc Frequency Range 100 MHz to 800 MHz Mixer input level -30 dBm
≤ -80 dBc Frequency Range ≥ 800 MHz Mixer input level -30 dBm
Apply for R3132N
≤ -70 dBc Frequency Range 100 MHz to 800 MHz Mixer input level +77 dBµV
≤ -80 dBc Frequency Range ≥ 800 MHz Mixer input level +77 dBµV
Apply for R3162/72
≤ -70 dBc Frequency Range 100 MHz to 800 MHz Mixer input level -30 dBm
≤ -80 dBc Frequency Range ≥ 800 MHz Mixer input level -30 dBm
≤ -100 dBc Frequency Range ≥ 3.3 GHz Mixer input level -10 dBm
Apply for R3182
≤ -70 dBc Frequency Range 100 MHz to 800 MHz Mixer input level -30 dBm
≤ -80 dBc Frequency Range ≥ 800 MHz Mixer input level -30 dBm
≤ -95 dBc Frequency Range ≥ 3.3 GHz Mixer input level -10 dBm
Instruments Required:
Instruments Qty. Recommended Model
Signal Generator 1 SMP04
Power Meter 1 NRVS
Power Sensor 1 NRV-Z55
Power Splitter 1 K241C
2 GHz Low-pass Filter 1 DEE-001172-1
Minimum Loss Pad 1
*1
HP11852B
RF Cable BNC(m)-BNC(m) 1 MI-09
RF Cable SMA(m)-SMA(m) 3 A01002
RF Cable K(m)-K(m) 1
*2
Adapter N(m)-SMA(f) 2
Adapter K(f)-K(f) 1
*2
*1 R3132N Only
*2 R3182 Only
