R3132 Series Spectrum Analyzer Operation Manual
5.1 General
5-4
Table 5-4 Instrument Required (1 of 3)
No. Instrument Specification
Recommended
Model
Qty.
1 Frequency Standard Output Frequency: 10 MHz
Stability: 5×10 e
-6
/day
Output Impedance
:50 Ω
Output Level: 1 Vpp or more
R3031
ADVANTEST
1
2 Frequency Counter Resolution: 0.1 Hz R5372
ADVANTEST
1
3 Signal Generator Frequency Range: 10 MHz to 18 GHz
Output Level: -15 dBm to +10 dBm
Stability: 1×10 e
-6
/year
SMP02
(with B11 option)
Rohde&Schwarz
1
4 Signal Generator Frequency Range: 10 MHz to 40 GHz
Output Level: -15 dBm to +10 dBm
Stability: 1×10 e
-6
/year
SMP04
(with B11 option)
Rohde&Schwarz
1
5 Signal Generator Frequency Range: 300 MHz to 2.2 GHz
Output Level: -20 dBm to +10 dBm
Residual SSB
Phase Noise
at 20 kHz offset: less than -116 dBc/Hz
SMIQ02E
Rohde&Schwarz
1
6 Signal Generator Frequency Range: 5 kHz to 1.5 GHz
Output Level: -20 dBm to +10 dBm
Pulse period: 40 µs to 45 s
Pulse width: 20 µs to 1 s
SMT02
(with B1, B3 and B4
option)
Rohde&Schwarz
1
7 Spectrum Analyzer Frequency Range: 100 Hz to 8 GHz R3267
ADVANTEST
1
8 Power Meter Compatible with NRV series
power sensors
dB relative mode
Resolution 0.01 dB
Reference Accuracy 0.9%
NRVS
Rohde&Schwarz
1
