R3132 Series Spectrum Analyzer Operation Manual
1.4.4 Power Cable
1-9
1.4.4 Power Cable
A detachable power cable with a three-contact plug is included with the spectrum analyzer. The protective
earth ground contact on the plug connects (through the power cable) to the accessible metal parts of the
instrument. For protection against electrical shock, insert the plug into a power-source outlet that has a
properly grounded, protective-ground contact.
The manufacturer ships a power cable, as ordered, with the spectrum analyzer. A list of other available
power cables is shown in Table 1-2. Contact your ADVANTEST representative or the local AD-
VANTEST Field Office for information on how to order these.
Figure 1-3 Power Cable
3-pin power cable
Ground pin
To AC power outlet
