R3132 Series Spectrum Analyzer Operation Manual
4.2.9 GPIB Command Codes
4-44
Table 4-18 Config
Table 4-19 Preset
Function Listener Code
Talker Request
Code Output Format
Title
ON
erase
LON /**/
LOF
LB?
–––
Label
–––
Printer Command Select
ESC/P
PCL
ESC/P Raster
PRTCMD ESC
PRTCMD PCL
PRTCMD ESCR
PRTCMD? 0:ESC/P
1:PCL
2:ESC/P Raster
Gray level set Gray
B/W Small
B/W Large
Color
S-Color Small
S-Color Large
PRT GRY
PRT MOS
PRT MOL
PRT COL
PRT SCOLS
PRT SCOLL
PRT? 0:Gray
1:B/W Small
2:B/W Large
3:Color
4:S-Color Small
5:S-Color Large
Paper Feed
ON
OFF
PFEED ON
PFEED OFF
PFEED? 0: OFF
1: ON
BMP output mode select
Color
S-Color
Gray
B/W
HCIMAG COL
HCIMAG SCOL
HCIMAG GRY
HCIMAG MON
HCIMAG? 0:Color
1:Gray
2:B/W
3:S-Color
File compression ON
OFF
HCCMPRS ON
HCCMPRS OFF
HCCMPRS? 0:OFF
1:ON
File Number HCFILE * HCFILE? Number
Reading Bitmap file ––– BMP? Binary data<EOI>
Device Select
Printer
Floppy
HCDEV PRT
HCDEV FDD
HCDEV? 0:Printer
1:Floppy
Print ON HCOPY ––– –––
10 MHz internal reference
signal source
10 MHz external reference
signal source
RFI
RFE
FREF? 0:INT
1:EXT
Number of trace points 501
Number of trace points 1001
TPS
TPL
TP? 0:501
1:1001
Function Listener Code
Talker Request
Code Output Format
Preset IP
*RST
–––
–––
–––
–––
