R3132 Series Spectrum Analyzer Operation Manual
3.3.8 EMC Key (EMC Measurement)
3-33
3.3.8 EMC Key (EMC Measurement)
This section describes the menu displayed when the
SHIFT
key and the 1(
EMC
) key are pressed.
Detector Mode Displays the Detector menu.
QP Displays the QP menu and detects the quasi peak value.
RBW Auto Automatically sets the resolution bandwidth. (NOTE)
RBW 200Hz Sets the resolution bandwidth to 200 Hz (available for OPT27
only). (NOTE)
RBW 9kHz Sets the resolution bandwidth to 9 kHz. (NOTE)
RBW 120kHz Sets the resolution bandwidth to 120 kHz. (NOTE)
NOTE: Set the appropriate sweep time for the specified RBW and
frequency span.
Set the sweep time to 1 sec for 200 Hz of frequency span
when the RBW is 200 Hz.
Set the sweep time to 1 sec for 10 kHz of frequency span
when the RBW is 9 kHz.
Set the sweep time to 1 sec for 100 kHz of frequency span
when the RBW is 120 kHz.
Peak Displays the Peak menu and detects the peak value.
RBW Auto Automatically sets the resolution bandwidth.
RBW 200Hz Sets the resolution bandwidth to 200 Hz (available for OPT27
only).
RBW 9kHz Sets the resolution bandwidth to 9 kHz.
RBW 120kHz Sets the resolution bandwidth to 120 kHz.
RBW 1MHz Sets the resolution bandwidth to 1 MHz.
Normal Switches to the current detector as set at Detector (the Trc Det
menu) in the
TRACE
.
Field Displays the Antenna menu. From here, select the antenna factor
you wish to correct for (5D2W cable, 10 m including the cable
loss).
TR1722 Corrects for half-wave dipole antennas (TR1722).
UHALP9107 Corrects for log-periodic antennas (UHALP9107).
