ADVANTEST R3132 Series User Manual

R3132 Series Spectrum Analyzer Operation Manual
5.1 General
5-5
Table 5-3 Instrument Required (2 of 3)
No. Instrument Specification
Recommended
Model
Qty.
9 RF Power Sensor Frequency Range: DC to 18 GHz
Input Level: 1 µW to 100 mW
Maximum SWR: 1.2 (18 GHz)
NRV-Z51
Rohde&Schwarz
1
10 Microwave Power
Sensor
Frequency Range: 50 MHz to 40 GHz
Input Level: 1 µW to 100 mW
Maximum SWR: 1.3 (40 GHz)
NRV-Z55
Rohde&Schwarz
1
11 Power Sensor
(75 Ω)
Frequency Range: 1 MHz to 2.5 GHz
Input Level: 100 pW to 13 mW
Maximum SWR: 1.2 (2.5 GHz)
NRV-Z3
Rohde&Schwarz
1
12 1 dB Step
Attenuator
Attenuation Range: 0 dB to 12 dB
Frequency Range: DC to 18 GHz
HP8494H
Agilent Technoro-
gies
1
13 10 dB Step
Attenuator
Attenuation Range: 0 dB to 70 dB
Frequency Range: DC to 18 GHz
HP8495H
Agilent Technoro-
gies
1
14 Attenuator Driver 11713A
Agilent Technoro-
gies
1
15 Terminator Impedance: 50 Ω RNA
Rohde&Schwarz
1
16 Terminator (75 Ω) Impedance: 75 Ω RNA
Rohde&Schwarz
1
17 3 dB Attenuator Impedance: 50 Ω
Attenuation: 3 dB
SMA(m)-SMA(f)
DEE-000685-1
ADVANTEST
1
18 20 dB Attenuator Impedance: 50 Ω
Attenuation: 20 dB
SMA(m)-SMA(f)
DEE-000480-1
ADVANTEST
1
19 50 to 75 Ω
Minimum Loss Pad
Frequency Range: DC to 2.2 GHz
Insertion Loss: 5.7 dB (nominal)
HP11852B
Agilent Technoro-
gies
1
20 Power Splitter Frequency Range: 10 MHz to 40 GHz
Insertion Loss: 6 dB (nominal)
K241C
Anritsu
1
21 Power Splitter Frequency Range: 10 MHz to 26.5 GHz
Insertion Loss: 6 dB (nominal)
1579
Weinschel
1
