R3132 Series Spectrum Analyzer Operation Manual
5.1 General
5-6
Table 5-3 Instrument Required (3 of 3)
No. Instrument Specification
Recommended
Model
Qty.
22 Power Devider Frequency Range: 20 MHz to 1.5 GHz
Isolation: greater than 18 dB
DDUL-20A-10G
Merrimac
1
23 Power Devider Frequency Range: 2 GHz to 18 GHz
Isolation: greater than 18 dB
DDUL-24M-10G
Merrimac
1
24 Low-pass Filter Cutoff Frequency: 2.2 GHz
Rejection (3 GHz): greater than 40 dB
Rejection (3.8 GHz): greater than 80 dB
DEE-001172-1
ADVANTEST
1
25 RF Cable Impedance: 50 Ω
BNC(m)-BNC(m)
Length: Approx. 1.5 m
MI-09
ADVANTEST
2
26 RF Cable Impedance: 50 Ω
SMA(m)-SMA(m)
Frequency Range: DC to 26.5 GHz
Maximum SWR: 1.45 at 26.5 GHz
Length: Approx. 0.7 m
A01002
ADVANTEST
3
27 RF Cable Impedance: 50 Ω
K(m)-K(m)
Frequency Range: DC to 40 GHz
Maximum SWR: 1.45 at 40 GHz
Length: Approx. 0.7 m
SF102
SUHNUR
3
28 RF Cable Impedance: 50 Ω
BNC(m)-BNC(m)
Length: Approx. 1.5 m
DCB-FF4894X01-1
ADVANTEST
1
29 RF Cable Impedance: 75 Ω
BNC(m)-BNC(m)
Length: Approx. 1.5 m
DCB-FFA701X01-1
ADVANTEST
1
30 Adapter N(m)-SMA(f) Generic 2
31 Adapter SMA(f)-SMA(f) Generic 1
32 Adapter N(f)-BNC(m) Generic 1
33 Adapter N(f)-BNC(m) 75 Ω Generic 1
34 Adapter N(m)-BNC(f) Generic 4
35 Adapter N(m)-BNC(f) 75 Ω Generic 2
36 Adapter K(f)-K(f) Generic 1
